ZT-380 Turret type transparent film three-dimensional packaging machine
ZT-380 Turret type transparent film three-dimensional packaging machine Download Email Print this Page
Products Name :ZT-380 Turret type transparent film three-dimensional packaging machine
Specifications
Brief introduction.

This machine is a general-purpose equipment for the three-dimensional packaging of rigid paper boxes and packaging products

 of different sizes with materials of cellophane PVC and BOPP film. Transparent paper (film) and a printed graphic or holographic

laser logo folding and sealing pulling line, after self-adhesive paste, can facilitate the folding and sealing of finished products and

 the function of anti-counterfeiting.

This machine is suitable for the wrapping of various medium-sized and square items of strip package, such as drugs, health care

products, nutritional supplements, food, daily cosmetics, stationery, VCD tapes, poker, cigarettes, etc. It is an ideal box-type

three-dimensional packaging equipment.



Performance structure and characteristics.
The packaging speed is adjustable, the packaging size is adjustable (need to change the mold), the heat sealing temperature is adjustable.
Functions (two anti and three enhancements).
Two anti: anti-counterfeiting / moisture-proof.
Three enhancements: improve the added value of the product/improve the grade of the product/improve the quality of the product decoration.


Main technical parameters.
Machine type: ZT-380 type
Production efficiency: 20-50 strips/min
Packaging size range: (L)60-280mm(W)50-200mm(H)30-80mm
Power source: 220V 50-60Hz
Total power: 4.25Kw
Overall dimension: 2800mm×960mm×1650mm(L×W×H)
Weight: 1000Kg
