Main technical parameters

HP-500B(design according to customer requirements is also available)
Maximum specification of paperboard PVC
Maximum specification of PVC  480×200mm
(design according to customer requirements is also available)

Cutting frequency                          8-25【 times/minute】
Travel range                                 40-200mm
Air pressure                                 0.5-0.8Mpa
Air flow                                         ≥0.5m3/min
Total power                                 380V  50Hz  11KW
Main motor power                            1.5KW
Outline dimensions                     4300×920×1850mm（L×W×H）
Machine weight                              2100Kg
