Brief introduction.
This equipment is a new generation of packaging equipment successfully developed independently by the company's scientific researchers through continuous improvement and innovation. It adopts human-machine interface, PLC control, encoder support, touch screen operation, automatic counting, adjustable stroke, precise and convenient, mechanical stepless speed regulation by friction wheel reducer, stable machine operation, applicable to various sizes of different specifications of paper and plastic packaging, easy to operate, durable, clean and hygienic, and equipped with Safety emergency stop device can ensure the production of emergency measures to increase the operating safety factor, is the most ideal packaging equipment.
Main performance.
PVC tray forming, automatic waste recycling, automatic feeding, synchronous printing of batch number, automatic detection.
Suitable objects:

This machine is suitable for packaging daily necessities, stationery, toys, small hardware, cosmetics, drugs and other paper-plastic packaging. Packaging objects such as: batteries, toothbrushes, needles, lip balm, pens, glue, sockets, bearings, etc., to improve the finished product grade.

Model:JS-500
Packing material :
PVC hard sheet (0.15-0.35)×430mm
Cardboard 200g-700g (designed according to user's requirement)
Compressed air :
Pressure 0.6-0.8Mpa
Air consumption ≧0.3m/min
Point energy consumption:380v50Hz 8kw
Mold cooling water: tap water or circulating water energy consumption 50L / h
Dimension:L×W×H 4800×1000×1500mm
Weight:1800kg
Production capacity: 10-30 strokes / min
Stroke range:50-185mm
Max. board area:500×195mm
Max. forming area and depth: 410×175×40mm
